Fire Garage Panel Insulated Sectional Doors 40mm 50mm Perspective Industrial Lifting
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DESEO |
| Certification: | CE/ISO9001:2008 |
| Model Number: | SD3000 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | NEGOTIATION |
| Packaging Details: | plywood package |
| Delivery Time: | 10-20 days depend on quantity |
| Payment Terms: | T/T |
| Supply Ability: | 200 PER MONTH |
|
Detail Information |
|||
| Type: | Industrial Door | Open Style: | Automatic,Remote Control & Manual |
|---|---|---|---|
| Door Material: | Steel,Aluminum Alloy | Feature: | Thermal Insulation |
| Surface Treatment: | Galvanized+Powder Coated | Color: | Customized Color |
| High Light: | Fire Garage Panel Insulated Sectional Doors,Insulated Sectional Doors 50mm,Industrial Insulated Sectional Lifting Door |
||
Product Description
What are overhead doors?
Overhead doors are closures where the door leaf panels are sandwiched into a rail system fitted in the available space ‘above your head’. There are different types of rail systems (or mountings) which can be used with overhead doors. The choice of mounting will also depend on the building and the space available. Do the rails go straight up (vertical mounting) or must the rails be deflected against the ceiling (low, standard or high mounting) or follow a sloping roof (mounting to follow roofline)? The overhead door system is used for both industrial doors in utility applications and for garage doors as it is extremely popular with house-builders.
Sectional door
The overhead door is currently the most popular industrial door on the market. The door is known by various names such as sectional door, section door or garage door, for example. There are many manufacturers producing this type of door on the market.
double layer of color coated steel sheet, insulate with polyurethan.
40mm or 50mm panel
galvanized steel parts.
380V motor
Filling: Polyurethene PUR 25-60-25-100% HFCKW free
Heat Transfer Coefficient1 (U): 1.0 W/m2K
Heat resistance of the panel: 1.484 m2 K/W
R Value; 1.66
K Value of the panel: 0.604 W/m2K
Sound insulation value of the panel: 26DB
