• Warehouse Galvanized Steel Frame Retractable Dock Door Shelter
Warehouse Galvanized Steel Frame Retractable Dock Door Shelter

Warehouse Galvanized Steel Frame Retractable Dock Door Shelter

Product Details:

Place of Origin: CHINA
Brand Name: DESEO
Certification: CE/ISO9001
Model Number: DS2800

Payment & Shipping Terms:

Minimum Order Quantity: 1 UNIT
Price: USD 800
Packaging Details: plywood package
Delivery Time: 7-20 days
Payment Terms: T/T
Supply Ability: 200 unit per month
Get Best Price Contact Now

Detail Information

Surface Finishing: Finished Product Name: Dock Shelter
Size: Customized Size Application: Warehouse,logistics,Cold Storage
Frame: Galvanized Steel Frame Special Function: Anti Finger Protection
High Light:

Retractable dock door shelter

,

warehouse dock door shelter

,

alvanized steel loading bay dock shelters

Product Description

Warehouse Galvanized Steel Frame Retractable Dock Door Shelter

we got the hydraulic dock leveler, it can be directly installed on the edge of platform instead of digging a hole. It is easy to install and use, also convenient for the maintenance. The up and down adjustable height can reach most of the trucks, and the loading capacity is satisfying.





Main Features:
High insulation and strong sealing make moisture, dust and insects almost eliminated from warehouses.

Application Scope:
Suitable for door shelter applications which have strict requirements for insulation,defferent type of vehincle and more wall load-bearing capability.

Technical Data:

Item Specification
Feature & Benefits a. Adopt insert seal working solution
b. Meet various type of truck dimensions and loading condition
c. Keep indoor temperature,cleaning & anti-wind
Surface Material a. Polyester fabric with PVC coating
b.Thickness of Frontal Curtain:2.5 - 3.0mm
Thickness of Side Curtain: 0.6 - 0.8mm
c. Density:2.7kg/m2
d. Strength at break:150N/mm
e. Fabric layer 2 layers
f. Wear-resisting,anti-mildew
g. Fireproof Grade: EU Grade II
h. Anti-tear Capacity:328kg ( vertical )×344kg ( horiental )
i. Anti-pulling Capacity:398kg ( vertical )×325kg ( horiental )
Size 3400(W)*3400(H) MM
Metal Frame Galvanized steel / Aluminium Alloy
Temperature Scope -20ºC ~ +80ºC
Color black / blue or customer-tailor



Warehouse Galvanized Steel Frame Retractable Dock Door Shelter 0Warehouse Galvanized Steel Frame Retractable Dock Door Shelter 1

Warehouse Galvanized Steel Frame Retractable Dock Door Shelter 2
