IP 54 Protection Class 0.20 Meter / Second galvanized Industrial Insulated Sectional Doors
|Place of Origin:||CHINA|
Payment & Shipping Terms:
|Minimum Order Quantity:||1 UNIT|
|Packaging Details:||plywood package|
|Delivery Time:||7-20 days|
|Supply Ability:||200 unit per month|
|The Material Of The Door:||Lightweight Aluminium Door Panels||Enegy Consumption:||Minimal Energy To Operate|
|Sevice Life:||Provide An Exceptionally Long Operating Life||Product Name:||Overhead Insulated Garage Door|
|Application:||Industrial||Surface Treatment:||Powder Coated|
sectional overhead door,
industrial sectional doors
The overhead sectional door is currently the most popular industrial door on the market,the door is known by various names such as sectional door,sectional door or garage door.
Overhead sectional doors are closures where the door leaf panels are sandwiched into a rail system fitted in the available space”above your head”.there are different types of rail systems which can be used with overhead doors.the choice of installation will depend on the building and the space available.it have standard lift, vertical lift and high lift three different lift way.
Minimal energy to operate,and provide an exceptionally long operationg life.
No more bulky, unsightly and cumbersome overhead railing systems using valuable overhead space.
Reduced overhead components means that areas can be fitted with other overhead equipment such as lifting devices.
No. of revolutions: 24 rpm
Protection class: IP 54
Limit Switch: Electronical
Door opening speed: 0.20 meter/second
Filling: Polyurethene PUR 25-60-25-100% HFCKW free
Heat Transfer Coefficient1 (U): 1.0 W/m2K
Heat resistance of the panel: 1.484 m2 K/W
R Value; 1.66
K Value of the panel: 0.604 W/m2K
Sound insulation value of the panel: 26DB
