• Steel Insulated Sectional Doors 220V/380V Automatic Remote Controlled
Steel Insulated Sectional Doors 220V/380V Automatic Remote Controlled

Steel Insulated Sectional Doors 220V/380V Automatic Remote Controlled

Product Details:

Place of Origin: CHINA
Brand Name: DESEO
Certification: CE/ISO9001:2008
Model Number: SD4600

Payment & Shipping Terms:

Minimum Order Quantity: 1 UNIT
Price: USD 800/UNIT
Packaging Details: plywood package
Delivery Time: 7-20 days
Payment Terms: T/T
Supply Ability: 200 unit per month
Get Best Price Contact Now

Detail Information

Open Style: Automatic,Rolling,Remote Control & Manual Surface Finishing: Finished
Position: Industrial,Garage,Exterior,Commercial Color: Custom
Size: Customized Size Application: Warehouse,Garage,Industrial
Name: Industrial Sectional Door
High Light:

sectional overhead door

,

sectional garage doors

Product Description

Finger Protection

Safety is important to today's homeowner. As your door closes, the exclusive finger protection system gently pushes fingers away from section joints.

High Strength & Resistance Material

Due to heavy-duty exterior and interior steel, polymeric coating keeps the door nice appearance, low maintenance, durable and reliable.

Air Tightness

The sealing system between door panels and around the door leaf increases the air tightness, prevents heat loss and blocks airflow between sections.



Feature:

- Copper Color, NEW & ELEGANT LOOK.

- Door panel fingr protection patent designed. Saftey use.

- Design with the Small Window & small door is available.

- Easy installation. Our doors has pre-installed & tested in our factory.

- Self-locking while the power off. Saves our worry on the safety even when the power get cut off.

- Quality guaranteed. Our industrial door workshop & products are CE certificated.



Technical Data:

Material options

1. 304 STAINLESS STEEL 0.38mm-0.48mm

2. Aluminum material door panel with polyethene foam filled

3. Galvanized steel plate, with any ral color

Door panel height 450mm & 550mm
Normal Color Porcelain white, light gray,coffee color and stainless steel color, or any Ral color.
Rail & Fitting

Hot dip galvanized steel rail and galvanized bracket & hinges.

Aluminum powder coated 2.8mm thick rail is also optional.

Sealing With full sealed, weather resistance & well protection & soundproof.
Control

Automatic & remote controlled.

Power rate: 220V/380V

Feature for door motorized system Route memorable, door self locking when power cut off, self-checking up, non hand nipping, safety operation.
Certification ISO & CE certificated.



No. of revolutions: 24 rpm

Protection class: IP 54

Limit Switch: Electronical

Door opening speed: 0.20 meter/second

Filling: Polyurethene PUR 25-60-25-100% HFCKW free

Heat Transfer Coefficient1 (U): 1.0 W/m2K

Heat resistance of the panel: 1.484 m2 K/W

R Value; 1.66

K Value of the panel: 0.604 W/m2K

Sound insulation value of the panel: 26DB
