Heat Preservation Industrial Sectional Doors , Steel Sectional Garage Doors 2mm Thickness

Heat Preservation Industrial Sectional Doors , Steel Sectional Garage Doors 2mm Thickness

Product Details:

Place of Origin: CHINA
Brand Name: DESEO
Certification: CE/ISO9001:2008
Model Number: SD4600

Payment & Shipping Terms:

Minimum Order Quantity: 1 UNIT
Price: USD 800/UNIT
Packaging Details: plywood package
Delivery Time: 7-20 days
Payment Terms: T/T
Supply Ability: 200 unit per month
Get Best Price Contact Now

Detail Information

Size: Customized Size Application: Warehouse,House,Garage,Industrial,Villa
Surface Treatment: Powder Coated,Any Color For Powder Coating Name: Industrial Sectional Door,Sectional Warehouse Garage Door
Surface Finishing: Finished Color: Customized Color
High Light:

Heat Preservation Industrial Sectional Doors

,

2mm thickness Steel Sectional Garage Doors

Product Description

Heat Preservation Industrial Sectional Doors , Steel Sectional Garage Doors 2mm Thickness


Description

It is one of most widely used industrial doors at present. Every factory can use such doors because its higher running
speed, high operation frequency, good thermal insulation, and low maintenance,compared with tradtional roller doors.

Features

Heat Insulation
The energy-saving polyurethane is high quality heat insulator, non-absorbing and wear-resistant material with R-value 13.73.

Finger Protection
Safety is important to today's homeowner. As your door closes, the exclusive finger protection system gently pushes fingers away from section joints.

High Strength & Resistance Material
Due to heavy-duty exterior and interior steel, polymeric coating keeps the door nice appearance, low maintenance, durable and reliable.



Technical Data:



Item Description
Material SUS 304 Stainless Steel,Aluminium Alloy,Color Coating Plate
Thickness of Panel Mateiral 0.326 / 0.45mm / 0.55mm / 0.6mm
Thickness of Guiding Rail Gualvanized Steel,thickness: 2mm
Thickness of Panel 40mm / 50mm
Width of Panel 430mm / 550mm
Density of Sandwiches 48kg/m3
Surface Treatment Power coating,thickness of coating:30um
Heat Preservation 4.5W/m.h
Wind Resistance Beaufort scale 11, 28m/s
Noise Level: ≤60db
Sound Insulation Level 24 Db
Fire Retardation: Class A
Speed 0.2-0.4m / s
Max Dimension 12m * 8m
Sealing Performance EPDM rubber all round sealing : two side, top, bottom,between door panels
Steel cord Flexible ,3.8mm
Power Supply 380V 50Hz / 220V 50Hz
Service Life 10 years
Emergency Operation Manual Hoist Chain to open the door in case of power off
Balance System a. Balance the weight of door through the torsion spring
b. Easily manual operation: 140N to open
c. Spring brake device:Anti-broken device
d. Service Life:100 thousand open & close
e. Prolong the service life of the motor
Safety Airbag protection, door anti-fall device, wire rope anti-break protection device.
Optional Item Window,pedestrian door





Application Scope:
The industrial sectional door is applied to the outdoor passage,logistics center and external door of factory.



Main Features:
Automatic,security,heat preservation,torsion spring balance system.
