Fast Gate Aluminum Transparent High Speed Spiral Door with 0.8m/s Closing Speed and 0.8m/s Opening Speed

Factory Direct Wholesale Fast Gate Aluminum Transparent High Speed Spiral Door with 0.8m/s Closing Speed and 0.8m/s Opening Speed

Product Description:

Hard shutter doors can withstand 100,000 switching tolerances.
Superior performance, strong structure.
The door panel adopts crystal transparent glass with transparency of more than 70%.
The door bars are kept at a certain distance in the spiral guide rail and are wound by a non-contact winding method.
The middle hinge of the door panel with a width of more than four meters will not loosen
The thickness of the steel side hinge is 5MM, and the bearing mode of the hinge side is designed to make the door plate not deformed.
High wear resistance, super quiet.
Smooth operation, no noise.
The door panel interface adopts small pinch-proof door panel leather strips.
The material is elastomer TPE.
It plays the role of sealing and silencing
Color coated aluminum plate and color coated steel plate are two materials, and the foam density is more than 50 kilograms per cubic meter. The hardness reaches more than 80 degrees.
Door width 250MM effective width 220MM. One square meter is 4.4 pieces.
Aluminum alloy material thickness is 44MM and 54MM two kinds, steel material thickness is 42MM, 52MM two kinds.

Features:

• Product Name: High Speed Spiral Door
• Motor Power: 0.75KW-5.50KW
• Opening Speed: 0.8m/s
• Control System: PLC Control
• Size: Customized as Order

This High Speed Spiral Door is perfect for your villa garage. It is an aluminum roll up door with a motor power range of 0.75KW-5.50KW. With an opening speed of 0.8m/s and a PLC control system, it is a great addition to your garage.

Technical Parameters:

What is the unique features of high speed Aluminum Alloy Doors?:

1) Aluminum Alloy lathes and foam inserted and viewing windows as standard
2) Emergency handle equipment for surviving
3) Given frictionless for lathes operation to longer the using life
4) Weight balance with springs and belt
5) Basically no maintenace on the whole door Operation
6) Good combination of outside door application and high cycle operation in warehouse
7) Smooth and fast delivery in the logistics area of factory
8) Lower your production cost including air condition expense and temperature difference
9) No more installation demand(choose rolling back or oval for space limitation)
10) Fast lead time to meet the fast and quick delivery

FAQ:

*What is a sectional door mainly used for?

A sectional door is used as an industrial entrance door for warehoused,factories and logistics buildings.

*How does a sectional door operate?
It opens vertically along tracks and is stored overhead, saving space inside and outside the building.

*Is the sectional door suitable for industrial use?
Yes, industrial sectional doors are designed for frequent operation and heavy duty applications.

*Does a sectional door provide insulation?
Yes, insulated panels help reduce heat loss and support indoor temperature control.

*Can sectional doors be used at loading dock areas?
Yes, they are commonly used as warehouse and loading dock entrance doors.

*Is the sectional door compatible with automation systems?
Yes, it can be equipped with motors, sensors, and access control systems.

*Is installation and maintenance complicated?
No, the sectional door structure allows easy installation and routine maintenance.

*Do you support OEM or ODM for sectional doors?
Yes, OEM and ODM services are available for different project requirements.
