Commercial 50mm-80mm Thickness Insulated Sectional Garage Door With Optional Ventilation
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DESEO |
| Certification: | CE/ISO9001 |
| Model Number: | SD3000 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 UNIT |
|---|---|
| Price: | NEGOTIATION |
| Packaging Details: | plywood package |
| Delivery Time: | 10-20 days depend on quantity |
| Payment Terms: | T/T |
| Supply Ability: | 500 UNIT PER MONTH |
|
Detail Information |
|||
| Product Name: | Insulated Sectional Doors | Insulation: | Polyurethane Foam |
|---|---|---|---|
| Panel Design: | Flat Or Contoured | Finish: | Powder Coated |
| Application: | Warehouse, Factory, Auto, Mall | Size: | Customized |
| Hardware: | High-quality Hinges, Locks, Handles, Etc. | Colors: | White, Brown, Gray, Etc. |
| Highlight: | 50mm Insulated Sectional Doors,80mm Insulated Sectional Doors,Commercial Insulated Sectional Doors |
||
Product Description
Commercial Sectional Doors 50mm-80mm Thickness Insulated Sectional Garage Door with Optional Ventilation
Product Description:
High performance color coated steel material thermal Insulated Sectional are a versatile and durable option for commercial and industrial settings, offering both functionality and energy efficiency. These sectional overhead doors are designed to provide reliable insulation, security, and ease of operation, making them ideal for a wide range of applications.
Available in a variety of colors including white, brown, gray, and more, these insulated sectional overhead doors can be tailored to complement the aesthetics of your building. The color options allow for seamless integration with your existing design scheme or the opportunity to make a bold statement with a contrasting hue.
Constructed with high-quality steel material, the Insulated Sectional Doors are built to withstand the demands of daily use in commercial and industrial settings. The steel construction provides durability and strength, ensuring long-lasting performance and protection for your property.
Features:
- Product Name: Insulated Sectional Doors
- Ventilation: Optional
- Application: Warehouse, Factory, Auto, Mall
- Colors: White, Brown, Gray, Etc.
- Size: Customized
- Panel Design: Flat Or Contoured
Technical Parameters:
| Ventilation | Optional |
| Hardware | High-quality Hinges, Locks, Handles, Etc. |
| Panel Design | Flat Or Contoured |
| Finish | Powder Coated |
| Colors | White, Brown, Gray, Etc. |
| Weatherstripping | Vinyl Or Brush |
| Size | Customized |
| Insulation | Polyurethane Foam |
| Material | Steel |
| Application | Warehouse, Factory, Auto, Mall |
Technical Data:
| Item | Description |
| Material | SUS 304 Stainless Steel,Aluminium Alloy,Color Coating Plate |
| Thickness of Panel Mateiral | 0.326 / 0.45mm / 0.55mm / 0.6mm |
| Thickness of Guiding Rail | Gualvanized Steel,thickness: 2mm |
| Thickness of Panel | 40mm / 50mm |
| Width of Panel | 430mm / 550mm |
| Density of Sandwiches | 48kg/m3 |
| Surface Treatment | Power coating,thickness of coating:30um |
| Heat Preservation | 4.5W/m.h |
| Wind Resistance | Beaufort scale 11, 28m/s |
| Noise Level: | ≤60db |
| Sound Insulation Level | 24 Db |
| Fire Retardation: | Class A |
| Speed | 0.2-0.4m / s |
| Max Dimension | 12m * 8m |
| Sealing Performance | EPDM rubber all round sealing : two side, top, bottom,between door panels |
| Steel cord | Flexible ,3.8mm |
| Power Supply | 380V 50Hz / 220V 50Hz |
| Service Life | 10 years |
| Emergency Operation | Manual Hoist Chain to open the door in case of power off |
| Balance System | a. Balance the weight of door through the torsion spring b. Easily manual operation: 140N to open c. Spring brake device:Anti-broken device d. Service Life:100 thousand open & close e. Prolong the service life of the motor |
| Safety | Airbag protection, door anti-fall device, wire rope anti-break protection device. |
| Optional Item | Window,pedestrian door |
Specifications:
1. Our factory's Qualified automatic industrial door reach to official standard of European Union, Complete set of industrial door has tested, checked and certified by Italy Test institute which is designated and Authorized by European Union
2. Industrial door 's each section panel joint is adopt "Finger-protection"(Pinch-resistant) safety Design in order to avoid any finger injury when door open and close.
3. Industrial door size and Color can be customized according to customer's requiremtns. Full range of Colors such as Green, Brown, Cream, Red, Grey, Blue, Black, Wood Golden Oak, Mahogany and Cherry colors, etc.
4. Double thickers layer of steel plate with Polyurethane Foam Inside --- Heat Insulation.
5. Industrial door with Double Track system in order to avoid any installation problem caused by lower headroom distance.
Packing and Shipping:
Product Packaging for Insulated Sectional Doors:
Each insulated sectional door is carefully wrapped in protective foam and plastic wrap to prevent any damage during transportation.
Shipping Information:
Our insulated sectional doors are shipped in sturdy cardboard boxes to ensure safe delivery. We partner with trusted shipping carriers to deliver your order in a timely manner.
