Product Details:

Place of Origin: CHINA
Brand Name: DESEO
Certification: CE/ISO9001
Model Number: HFD3000

Payment & Shipping Terms:

Minimum Order Quantity: 1 UNIT
Price: 1200 USD
Packaging Details: plywood package
Delivery Time: 10-20 days depend on quantity
Payment Terms: T/T
Supply Ability: 200 PER MONTH
Get Best Price Contact Now

Detail Information

Product Name: High Speed Spiral Door Wind Resistance: ≤2.0KN/m2
Size: Customized As Order Opening Speed: 0.8m/s
Safety System: Photoelectric Sensor Power Supply: 220V/50HZ
Control System: PLC Control Motor Power: 0.75KW
Highlight:

Aluminum High Speed Spiral Door

,

220V/50HZ High Speed Spiral Door

,

0.8m/s High Speed Spiral Door

Product Description

Efficiency Safety Efficiency Aluminum Transparent High Speed Spiral Door Opening Speed 0.8m/s Power Supply 220V/50HZ for 220V/50HZ

Product Description:

High speed spiral door is a new high-tech product,the techology is in the advanced level in the world.

it have a luxury apperance .

the highest performance industrial door

High speed spiral door surface is very smooth , and all moving parts are strictly designed in accordance with European safety standard(D IN EN 12604)





With spiral round non-contact track , the sectional curtains won't connect with each other when roll up , the curtain material won't wear, distort and run fast without noise.





The Spiral door offers high-speed operation for high-traffic situations and rigid aluminum slat construction that eliminates the need for a second security door. Crisp lines give the Spiral door a stylish look that's great for many types of commercial, automotive retail, government, institutional and industrial applications. The Spiral door is ideal for automotive dealerships, government, parking and security.



it can be configured for a wide range of opening and closing speed, allowing you to precisely set the best speed for your application

Features:

  • Product Name: High Speed Spiral Door
  • Name: High Speed Spiral Door
  • Life Span: ≥5 Million Times
  • Color: Customized As Order
  • Power Supply: 220V/50HZ
  • Temperature Range: -20℃~+50℃



Efficiency Safety Efficiency Aluminum Transparent High Speed Spiral Door Opening Speed 0.8m/s Power Supply 220V/50HZ 0

Technical Parameters:

Product Name
High Speed Aluminum Spiral Door
Special Option
Servo System Motor
Maximum Door Size
W8000mm*H6500mm
Opening speed
0.8 - 2.5 m/s, adjustable
Standard Control Mode
Push wall switch
Operation way
Remote control, Access Control, Magnetic loop,Radar, Pull Rope Switch
Emergency Operation
Available
Door Panel
Aluminum sandwich construction, PU foamed


Hardware Material
Frame and Cover Box - Galvanized steel / 304 stainless steel
Inner Track Guide - Aluminum extrusion
Vision panel - Optional Double PC sheet window
Motor Brand
SNMA, SEW, SIEMENS,SEJ,SERVO
Motor Power
0.75kw - 5.50kw
Input Voltage
220V 50HZ/380V 50HZ
PLC Brand
SIEMENS / MITSUBISHI / OMRON /KEWEI
Inverter / AC Driver
MITSUBISHI,SIEMENS,SHIHLIN
Revolving Encoder
TOFI (INCREMENTAL ENCODER)
Control Box
Safety class- IP55, Variable speed drive
Safety Performance
Infrared photo sensor, Safety airbag edge protection
Wind Resistance
Class 12 (Beafourt Scale)
Operating Life
500,000 cycles
Working Temperature
-25 °C to 65 °C
Warranty
1 year for electric parts, 5 years for mechnical parts
Aluminum Alloy


Construction:

Double-walled 220mm aluminum slats

Integral weatherseal between the aluminum slats

Heavy-duty hinge system for door panel assembly

Durable powder coated steel side columns and head console (excludes US/R models)

Extension springs in side column



              Efficiency Safety Efficiency Aluminum Transparent High Speed Spiral Door Opening Speed 0.8m/s Power Supply 220V/50HZ 1

Efficiency Safety Efficiency Aluminum Transparent High Speed Spiral Door Opening Speed 0.8m/s Power Supply 220V/50HZ 2

              Efficiency Safety Efficiency Aluminum Transparent High Speed Spiral Door Opening Speed 0.8m/s Power Supply 220V/50HZ 3

Options:

Insulated slats

Vision slats

Ventilated slats

Hood and motor covers

Classic RAL and custom color match powder coated finish





 Efficiency Safety Efficiency Aluminum Transparent High Speed Spiral Door Opening Speed 0.8m/s Power Supply 220V/50HZ 4

Efficiency Safety Efficiency Aluminum Transparent High Speed Spiral Door Opening Speed 0.8m/s Power Supply 220V/50HZ 5

Packing and Shipping:

Product Packaging:

The High Speed Spiral Door is carefully packaged in a sturdy cardboard box to ensure safe delivery. The door components are securely wrapped in protective materials to prevent any damage during transit.

Shipping:

Once the High Speed Spiral Door is packaged, it will be shipped via a reliable courier service. You will receive a tracking number to monitor the delivery status of your order. The door will be delivered to your specified address within the estimated timeframe provided by the shipping carrier.
