Mechanical Safe and Efficient Workshop Automatic Dock Plate Dock Door Levelers 25000-40000LBS Safe Design Platform Size Customizable
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DESEO |
| Certification: | CE/ISO9001 |
| Model Number: | DL2200 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 UNIT |
|---|---|
| Price: | USD 800/UNIT |
| Packaging Details: | plywood package |
| Delivery Time: | 10-20 days depend on quantity |
| Payment Terms: | T/T |
| Supply Ability: | 200 PER MONTH |
|
Detail Information |
|||
| Finish: | Powder Coated, Galvanized | Controls: | Push Button, Foot Pedal, Handheld Remote |
|---|---|---|---|
| Product Name: | Loading Dock Leveler | Capacity: | 10,000-20,000 Lbs |
| Color: | Customized As Order | Warranty: | 2 Year |
| Deck Height: | Customizable | Lip Length: | Customizable |
| Highlight: | Mechanical dock door levelers with safe design,Automatic dock plate for heavy loads,Customizable loading dock leveler platform |
||
Product Description
Mechanical Safe and Efficient Workshop Automatic Dock Plate Dock Door Levelers 25000-40000LBS Safe Design Platform Size Customizable
Product Description:
Loading dock levelers are essential equipment used to facilitate the efficient loading and unloading of goods by compensating for height differences between various transport vehicles and loading docks.
Types: There are several types of dock levelers, including telescopic dock levelers, which improve logistics efficiency by forming a slope transition between the vehicle and the platform, and scissor levelers, which are height-adjustable platforms for significant height differences.
Functionality: They can be activated automatically or mechanically and come in various styles, such as pit-style or edge-of-dock.
Telescopic Dock Levelers can achieve a safe and fast loading and unloading process, improve logistics loading and unloading efficiency, effectively adjust the height difference between the bottom plate of different transport vehicles and the platform, forming a slope transition between the rear of the vehicle and the platform, enabling the loading and unloading process to be completed in one go, avoiding accidental damage and unnecessary risks.
For places with high insulation and sealing requirements such as cold storage, Telescopic Dock Leveler is a better solution. A Telescopic Dock Leveler is installed on the inner side of the cold storage insulation sliding door. After the door is closed, it directly falls to the bottom of the foundation pit, blocking the air convection between indoor and outdoor areas, thus achieving a fully sealed design of the unloading position and reducing energy loss.
Technical Parameters:
| Product Name | Loading Dock Leveler |
|
|
Dock Leveler Specification:
Spring Assisted Action
Raise and lower the ramp with less than 50 lbs. of force! The dock levelers high torsion spring assembly takes the work out of raising and lowering the dock leveler making it easy for almost any of your personnel.
Operating Range
The standard mechanical Edge of Dock Leveler is designed for operation ±5" above and below dock level for gas forklifts or ±3” for all other equipment types.
Our Low Dock Solution
For loading docks too low for this working range we also offer low dock ramps designed to be mounted to the floor of your loading dock opening. By effectively raising the level of your dock an edge of dock leveler may be mounted at a height suitable to your freight needs.
Our low dock ramps are also available for those with existing dock levelers mounted below their ideal operating range.
Edge of Dock Leveler Design
The Dock Leveler is designed to accommodate a maximum of five inches above and below the dock, providing 18.5% grade down and 20% grade up. This is acceptable for most gas or propane forklifts but is not suitable for most pallet trucks or many electric forklifts.
Packing and Shipping:
Product Packaging and Shipping for the Loading Dock Leveler
FAQ:
Q1:How to solve the trouble in using application?
A1:lt is ok to contact us via email and other chatting apps to get the online supporting
Q2:How to install the door,is it difficult?
A2: We'll provide the installation manuals and videos, and support the whole processing
Q3:Can you do the full set products according to my project drawing?
A3: Yes we can, our engineer will check your project drawings to make sure its accuracy for each different fittings and quantity
Q4:How about your payment terms?
A4: The payment procedure is 50% payment advanced by T-T within 5 days after Purchasing Order, 50% payment paid against the copy of BL by T-T.
Q5: Do you have the professional sales-after service?
A5: Yes, we have all videos to show the whole processing and also we have the richexperience based on our more than 10 year exporting experience.We made many standard terminals and it is for customer to EASY PLUG IN and finish the parameter setting.
