8T /10T Capacity Hydraulic Tons Warehouse Customizable Platform Size Workshop Automatic Dock Plate Dock Door Levelers 25000-40000LBS Safe Design
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DESEO |
| Certification: | CE/ISO9001 |
| Model Number: | DL2200 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 UNIT |
|---|---|
| Price: | USD 800/UNIT |
| Packaging Details: | plywood package |
| Delivery Time: | 10-20 days depend on quantity |
| Payment Terms: | T/T |
| Supply Ability: | 200 PER MONTH |
|
Detail Information |
|||
| Color: | Customized As Order | Finish: | Powder Coated, Galvanized |
|---|---|---|---|
| Platform Size: | Customizable | Deck Height: | Customizable |
| Capacity: | 10,000-20,000 Lbs | Safety Features: | Safety Chains, Safety Curbs, Safety Bars |
| Warranty: | 2 Year | Power Source: | Electric, Hydraulic |
| Highlight: | customizable dock door leveler,heavy-duty automatic dock plate,workshop dock leveler installation |
||
Product Description
8T /10T Capacity Hydraulic Tons Warehouse Customizable Platform Size Workshop Automatic Dock Plate Dock Door Levelers 25000-40000LBS Safe Design
Product Description:
A loading dock leveler is a device used to bridge the gap between a loading dock and a transport vehicle, facilitating the efficient loading and unloading of goods. Here are some key points:
*Purpose: They compensate for height differences between various lorry platforms and docks, ensuring a smooth transition for loading and unloading.
*Types: Common types include telescopic dock levelers, scissor levelers, and edge-of-dock levelers, each designed for specific loading conditions.
*Functionality: They can be activated automatically or mechanically and are available in various sizes and capacities to meet different loading dock requirements.
*Benefits: Using dock levelers improves logistics efficiency, reduces the risk of accidents, and protects goods from damage during the loading process.
For more detailed information, you can refer to the sources provided.
![]()
Features:
| Loading capacity | 6T/8T/10T |
| Equipment dimension | L2000mm*W2300mm*H550mm |
| Pithead dimension | L2000mm*W2330mm*H560mm |
| Adjustable range | 300/-300mm |
| Adjust time | Up≤16S,Down≤10S |
| Main plate thickness | 6mm/ 8mm Bao Steel |
| Lip plate thickness, size | 12mm,400mm |
| Available color | Blue, green |
| Motor power | 0.75kW, 380V, 50Hz |
| Hydraulic oil pressure | 8Mpa±1Mpa |
| Hydraulic tank capacity | 6L |
| Working temperature | -20℃~+50℃ |
| Bumper | L380*W180*H100mm |
The Benefits of Using a Loading Dock Leveler:
Investing in the right loading dock leveler can yield significant returns in terms of safety, productivity, and cost savings.
*Enhanced Safety: By creating a secure and even surface, dock levelers dramatically reduce the risk of accidents such as forklift tip-overs, falls, and injuries to personnel.
*Increased Productivity: A smooth and efficient loading and unloading process means faster turnaround times for trucks. This allows for a higher volume of goods to be moved in a shorter period.
*Protection of Goods and Equipment: The jarring and bumping that can occur when moving goods over an uneven surface can lead to product damage. A leveler provides a smooth ride, protecting both the cargo and the material handling equipment from unnecessary wear and tear.
*Improved Ergonomics: By providing a powered and automated solution, dock levelers reduce the physical strain on workers, leading to a more ergonomic and less injury-prone work environment.
![]()
Packing and Shipping:
Product Packaging and Shipping for Loading Dock Leveler
The Loading Dock Leveler is carefully packaged to ensure safe transportation and delivery. Each leveler is securely wrapped with protective materials to prevent damage during handling and shipping. The unit is then placed on a sturdy wooden pallet and strapped tightly to avoid any movement.
![]()
FAQ:
Q1: What is our delivery lead time?
We usually have inventory of standard products. If not, we need 7-10 days to produce standard products and 10-15 days for customized products.
Q2: Do we accept customization?
Of course, we can customize products according to your requirements. We will have professional customer service to liaise with you on the details.
Q3: What is our guarantee?
We offer you a one-year warranty period, during which we can provide you with parts that are not damaged by human factors free of charge.
Q4: What are our advantages?
We specialize in producing hydraulic lift equipment for logistics, warehouses, factories, and buildings. We are a large-scale lifting platform manufacturing enterprise that integrates research and development, production, and sales, and we have many years of export experience.
Q5: Is the elevator easy to install?
Answer: Yes, it's not difficult. The elevator is shipped as a finished product, and we provide you with 3D installation drawings and videos. In addition, we will guide you through online installation.
Q6: If you have any further questions, please contact our online customer service and we will patiently answer them for you.
