OEM Wholesale Industrial Style Outdoor Waterproof High Durability Adjustable Loading System dock door shelter Customized Color

Product Details:

Place of Origin: CHINA
Brand Name: DESEO
Certification: CE/ISO9001
Model Number: IDS3000

Payment & Shipping Terms:

Minimum Order Quantity: 1 UNIT
Price: 1000 USD
Packaging Details: plywood package
Delivery Time: 7-20 days depend on quantity
Payment Terms: T/T
Supply Ability: 200 UNIT PER MONTH
Get Best Price Contact Now

Detail Information

Function: Protection From The Elements Design: Modern
Surface Finishing: Finished Protection: Weatherproof
Fixed: Galvanized Steel Liner Color: Customized Color
Material: PVC Plastic Rubber Advantage: Suitable For Trucks Of More Sizes
Highlight:

industrial waterproof dock door shelter

,

adjustable loading system shelter

,

customized color dock shelter

Product Description

OEM Wholesale Industrial Style Outdoor Waterproof High Durability Adjustable Loading System dock door shelter Customized Color

Product Description:

DESEO offers a wide variety of loading dock shelters to fit your loading dock design objectives and budget. The seal at the top is created with a curtain designed to reach down to the trailer. This header curtain may be weighted or simply constructed of fabric, and can be self-adjusting or require pull-rope adjustment, depending on the model. The side curtains may or may not be equipped with features to seal around trailer door hinge gaps.
DESEO’s dock shelters are equipped with features that allow them to match the sealing effectiveness of foam seals. The benefits of dock shelters in general relative to dock seals include:
The ability to fit larger dock door opening.
Provide unobstructed access to trailer load.
Service a wide variety of trailer heights and style.
Less subject to damage from daily wear and tear since they are not designed to be compressed by the trailer and therefore are not subject to extreme pressure in normal use.
Less pressure on building wall.
The disadvantages of dock shelters relative to foam seals are that some models provide substantially less sealing efficiency, especially when trailer door hinge gaps are left unsealed. In addition, if shelter side frames are constructed of non-impactable materials, they can be severely damaged upon trailer impact, requiring costly repair or replacement.
As a category, dock shelters are generally more expensive than dock seals. The price difference between the models is based primarily on both durability and sealing effectiveness. Dock Shelter price reflects the number and type of features included to provide tight sealing along trailer sides, upper corners, and across the top. Price differential between models also reflects differences in side frame construction and related ability to withstand damage from the impact of trailers backing in off center.
DESEO’s line-up of dock shelters provides additional detailed features and information on the durability and sealing efficiency so you can make the most informed decision for your warehouse or facility.





OEM Wholesale Industrial Style Outdoor Waterproof High Durability Adjustable Loading System dock door shelter Customized Color 0

Features:

Control System
DESEO brand
Single-phase or Three-phase Power Supply
380,50Hz
Power
0.75kw
Control Unit
Extraposition
Control Module Protection Level
IP54
Average Inflating Time of Airbag
20 Seconds
Working Temperature
From-35℃ To + 70℃
PVC Curtain Plate
3.6kg/m
Thickness
3mm
Unit Weight
3.6kg/m
Air Sac
0.5mm
Size
Customized
Thickness
0.5mm
Unit Weight
0.4kg/m
Maximum Tensile Capacity
Greater than 290 N/m m of ²
Foam Board
Polyurethane Foam
Thickness
50mm

Parameters:

Front Curtain Panel Parameters
Longitudinal Tensile Resistance
>550N
Lateral Tensile Force
>900N
Maximum Tensile Strength
250N/mm²
Metal Friction Coefficient
0.3
PVC Friction Factor
0.4
Thickness
3mm
Unit Weight
3.6kg/mm
Working Temperature
From-35℃ to + 90℃
Side PVC Cord Fabric Parameters
Stretching Resistance
250N
Thickness
0.5mm
Unit Weight
0.7kg/mm
Working Temperature
From-35℃ to + 70℃
Aluminum Alloy Frame Parameters
Back End Profile Size
50*44*4mm
Front End Profile Size
45*44*4mm
Frame Size
50*25*4mm
Front Pressing Plate Size
34*4.8mm



OEM Wholesale Industrial Style Outdoor Waterproof High Durability Adjustable Loading System dock door shelter Customized Color 1

Packing and Shipping:

OEM Wholesale Industrial Style Outdoor Waterproof High Durability Adjustable Loading System dock door shelter Customized Color 2



FAQ:

Q1:Are you a trading company or a factory?
We are a Chinese manufacturer. We have a strong technical team / R & D team. Our products are very good in quality and competitive in price. So, they sell well.
Q2:Can you do the full set products according to my project drawing?
Of course, we have our own design parameters. we can design and product the whole set Logistics equipment, also support all kinds of customization. If you need, our engineer will check your project drawings to make sure its accuracy for each different fittings and quantity.
Q3:Do you produce other products? Do you also produce accessories?
Yes, we also produce various types of hydraulic platforms and loading dock leveler, spiral door, industrial dock seal, high speed PVC Door, lifting door, transparent door, PVC door and other logistics transportation equipment; We produce parts by ourselves in order to control quality and cost.
Q4:Can you give us a discount?
Because we have the most advanced production equipment, so in improving the quality of products but also effectively control the cost, you can buy at a very affordable price to your satisfaction. If you need a large quantity or consider long-term cooperation, the price will be more favorable.
Q5:How is the delivery time?
We will ship the goods after 25 working days after receiving the full payment.
