Robust PVC Rapid Roller Doors Tough Traff Coated Polyester Anodized Aluminium
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DESEO |
| Certification: | CE/ISO9001 |
| Model Number: | HSD2000 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 UNIT |
|---|---|
| Price: | USD 1000/UNIT |
| Packaging Details: | plywood package |
| Delivery Time: | 7-20 days |
| Payment Terms: | T/T |
| Supply Ability: | 200 unit per month |
|
Detail Information |
|||
| Applications: | Indoor, Outdoor,industry | Position: | Industrial |
|---|---|---|---|
| Framework: | Anodized Aluminium | Cloth Color: | Red, Yellow, Blue, White, Full Transparent, Etc. |
| Made From: | PVC Coated Polyester | ||
| High Light: | Robust Rapid Roller Doors,Coated Polyester Rapid Roller Doors,anodized aluminium Rapid Roller Doors |
||
Product Description
Applications:
* Indoor, outdoor which requests resistant the wind/ temperature .
* Heavy industry, Light industry, food industry, electronics, pharmaceutical, warehousing, packaging, printing, chemical industry, automobile, manufacturing.
* The Industries In high request in environmental health.
How quickly do rapid roller doors open and close?
While rapid doors can open and close at 2 to 2.5 metres per second,their speed is largely influenced by the opeining size and the environment(whether external or internal)in which it's installed.
For example,a smaller internal door that deals only with low air pressure can have fibreglass(GRP) battens and will open quickly.On the other hand,a larger external door exposed to wind will need to be more robust(with more mass),and therefore will need to run a little more slowly.
Technical Parameter:
| Tensile strength(wrap/weft) | 5700/5100N/5m |
| Tearing strength(wrap/weft) | 900/800N |
| Use temperature | -30°C- +70°C |
| Fire protection Level |
French standard NF-P92-503 Or German standard M2 DIN 4120 B1 |
Features
1) Safety
radar sensor,photo sensor,air safety bag include
2) Tightness
Aluminium alloy seal brushes are added to either side of the slide way,reducing noise and enhancing tightness,there is flexible PVC banner at bottom,making it cling to all kinds of uneven ground closely and meeting the standard of seal.
3) Power
SERVO or SEW motor,380V,50HZ, IP55 Power:0.75KW-----1.50KW
4) Speed of opening and closing:
Opening speed:0.8m-1.6m/s(adjustable),1000-1500 times/day
5) Control box
Shihlin brand Frequency changer,KEWEI brand PLC Programming controlling,circuit breaker,fuse gear and relay can be compatible with common protector.
6) Door structure:
Door frame: 2.0mm galvanized steel sheet (cold-roll steel sheets)and baking varnish
